9000BTU Under Bench RV Air Conditioner



9000BTU Under-Bench RV Air Conditioner



Explore the great open road with NF's newest RV under a bench air conditioner package unit. Intended for under-the-bench installations, this low-profile and highly durable package system will keep your motor vehicle at a cozy temperature all year round, and do so quietly. Easily attach three ducts to serve separate areas of the dwelling, with options to connect to the front or side of the system. Control the system using the wall-fixed thermostat, or from the comfort of your bed using the convenient handheld remote controller. With ultra-quiet performance, sleek design, and very low input power requirements, this rugged plug-in system will be one of your favorite companions on those long-haul journeys, day in and day out.





Model	NFHB9000
Rated Cooling Capacity	9000BTU
Rated Heat Pump Capacity	9500BTU
Extra electric heater	500W (but 115V/60Hz version has no heater)
Power Supply	220-240V/50Hz, 220V/60Hz, 115V/60Hz
Refrigerant	R410A
Compressor	vertical rotary type, Rechi or Samsung
System	one motor + 2 fans
Total frame material	One piece, EPP Metal base
Unit Sizes (L*W*H)	734*398*296 mm
Net Weight	27.8KG



Product Structure:







Product Advantages:

1. Flexible air supply

Flexible arrangement of hoses for air supply, cold air can be led to the required position and cooled.



2. Integrated design

Integrated air-conditioning design, no outdoor unit, small size, extremely easy to install and maintain.





The product details include a full set of installation accessories for the product, including air ducts, remote controls, control panels, etc. It also includes product packaging images, which can be seen in the details.





The figure below shows the simple installation diagram and installation location of the product. Please refer to the instruction manual for specific installation information.





This air conditioner has passed the professional CE certification. The CE certificate and model can be seen in the picture below. The first model in the second picture is the model of this air conditioner.



1. Q: What is an under-chassis RV air conditioner?
A: An under-chassis AC is a type of RV air conditioning unit mounted beneath the vehicle, saving roof space and reducing wind resistance while driving. It provides efficient cooling like traditional rooftop units but with a lower profile.

2. Q: What are the advantages of under-chassis ACs?
A: Key benefits include:
(1) Improved aerodynamics (better fuel efficiency).
(2) Freed-up roof space for solar panels or storage.
(3) Quieter operation (reduced noise inside the RV).
(4) Less visible, maintaining a sleek RV exterior.

3. Q: How does an under-chassis AC differ from a rooftop unit?
A: While both cool effectively, under-chassis ACs:
(1) They are mounted below the floor, not on the roof.
(2) Often use a ducted system for even airflow.
(3) May have higher installation complexity due to plumbing and wiring routing.

4. Q: Why is my under-chassis AC not cooling properly?
A: Common causes:
(1) Dirty air filters or blocked ducts.
(2) Low refrigerant levels (needs professional service).
(3) Electrical issues (e.g., tripped breaker or faulty thermostat).

5. Q: Are these units compatible with all RV types?
A: Not universally. Check:
(1) Clearance space under your RV.
(2) Electrical system capacity (e.g., 30A vs. 50A RVs).
(3) Ductwork compatibility (some models require specific layouts).

6. Q: Where can I get repairs or parts?
A: Contact authorized dealers or RV service centers.
