Electric Bus Water Pump 600W





This electronic water pump adopts a brushless DC motor to drive the impeller, enabling stepless speed regulation, and a matching drive controller controls the brushless motor.

It can be widely applied in automotive engine primary cooling systems, auxiliary cooling systems, battery pack cooling systems as well as energy storage equipment. By powering the circulation of coolant to different heat dissipation components, it helps various thermal management systems achieve optimal performance and guarantees their stable and reliable operation.

Moreover, the operating speed of this electronic water pump can be regulated via the CAN bus, allowing flexible adjustment of its operating state. Besides the fundamental functions, the water pump is also equipped with complete protection mechanisms to ensure safe operation.



Basic Parameters



Model Number	02.03.732.3405
Ambient Temperature	-40ºC~+125ºC
Storage temperature	-50ºC~+125ºC
Rated Voltage	24V
Voltage Range	DC18V~DC32V
Waterproofing Grade	IP67
Service life	≥20000h
Noise	≤60dB at a distance of 1 meter
Input power	600W
Flowing	≥3500L/h@24m



Color	Black
Environmental Rating	Complies with RoHS environmental requirements
Frame Material	ADC12, PPS+GF30
Sealing Performance	Test pressure 350KPa, test time 5s, leakage ≤80Pa
Working Principle	Centrifugal pump
Application	Vehicle-mounted water circulation cooling system









1. Pump cover;

2. Impeller assembly;

3. Casing and stator assembly:

4. Cable outlet assembly;

5. Shielding sleeve

6. Rotor assembly;

7. Rear bearing housing assembly;

8. PCB assembly;

9. Motor rear cover.





Recommended installation angle



a) After installation, maintain the angle between the center line of the inlet and the horizontal plane between -5° and +5°, as shown in the figure below.







b) After installation, maintain the angle between the center line of the water outlet and the horizontal plane between 5° and +90°, as shown in the figure below.







Reverse Connection Protection:



Within the normal operating voltage range, if the power supply polarity is reversed, the water pump will stop working and will not provide any feedback signal, but it will not be damaged. It will function normally after the power supply is reconnected correctly.





Overvoltage Protection:



When the power supply voltage exceeds 33V (±0.5V) for 0.5 seconds, the water pump will stop working and provide a fault signal. When the voltage drops below 32V (±0.5V) for 1 second, the water pump will restart.



Undervoltage Protection:



When the power supply voltage is below 17V (±0.5V) for 0.5 seconds, the water pump will stop working and provide a fault signal. When the voltage exceeds 18V (±0.5V) for 1 second, the water pump will restart.
