Water Pumps For Electric Bus



Water Pumps For Electric Bus



Adopting a brushless DC motor, NF Water pumps for electric bus support stepless speed regulation with accurate speed control via a dedicated controller.



Ideal for cooling systems of vehicle engines, battery packs and energy storage units, it efficiently circulates coolant to dissipate heat, enhances thermal management and guarantees stable equipment operation.





These Water pumps for electric bus are constructed as brushless DC canned motor pumps.

Major components:



• Brushless DC motor: incorporates rotating‑side components including impeller unit, shielding unit, flange and rotor unit, together with the stator housing.

• Control unit (PCB assembly): supports signal exchange with vehicle ECU and governs motor operating performance.

• Pump cover: structured for installation and interfacing with vehicle engines and cooling loops.

• Motor back cover: fitted with a purpose‑built connector for vehicle‑side electrical hookup.







Product Model	Electronic water pump
Rated Voltage	DC24V
Operating Voltage Range	DC18V～32V
Rated Current	≤11.5A
Input Power	240W
Rated Flow Rate	≥3000L/h@13m
Maximum Head	≥20m
MOQ	1PC
Port	Tianjin/Beijing





1. Constant power output: maintains fixed pump power under operating voltage ranging from 18V to 32V.

2. Overtemperature protection: the water pump shuts down once ambient temperature exceeds 100 ℃ (threshold temperature).

To extend service life, install the pump in areas with lower temperature or good airflow.

3. Soft start function.

4. PWM signal control capability.
