3kw Steering Pump
Hebei Nanfeng Group has a history of producing electric vehicle parts for over 30 years. Our company is the largest auto parts manufacturer in China. The steering motor is specially designed for electric vehicles and electric trucks and supports OEM customization.
Description
3kw Steering Pump
Products Description
The electric motor pump EHPS is a combination of "drive motor + steering hydraulic power pump". It is driven by an electric motor instead of a traditional engine, providing steering hydraulics for hybrid buses and electric buses. It is the power source and core component of the steering system.
|
Steering motor assembly performance parameters |
|||
|
Motor model |
EHPS-1018R3/19XB-010 |
||
|
Rated power (KW) |
3 |
Peak power (KW) |
7.5 |
|
Guangdong fixed voltage (VAC) |
237 |
Temperature control resistor type |
None |
|
Rated current (A.) |
12 |
Number of motor poles: |
8 poles (4 pairs of boards) |
|
Peak current (A) |
33 |
Stator wire resistance (0) |
0.8 (at 20℃) |
|
Rated frequency (HZ) |
66.67 |
Rated speed (r/min) |
1000 |
|
Peak torque (N.m) |
72 |
Rated torque (N.m) |
30 |
|
D-axis inductance|mH) |
6.88 |
Q-axis inductance|mH) |
10.87 |
|
Rated efficiency (%) |
≥92% |
Working day |
S2~3min |
|
Insulation level |
H level |
Cooling method: |
natural cooling |
|
Protection grade |
IP67 |
Working environment temperature: |
-40℃~+85℃ |
|
Motor type: |
SVC position sensorless permanent magnet synchronous motor |
||
Products feature
2. A smooth, impact-resistant flexible coupling is used for power transmission, significantly extending its service life.
3. The overall protection level reaches IP67, and a double insulation design ensures no electrical conduction between the motor and oil pump.
4. The motor and steering pump housings are constructed entirely of aluminum alloy, offering excellent performance such as low noise, light weight, and rapid heat dissipation
