What is a self-generating diesel air heater?
This product is especially suitable for occasions when there is no external power and it needs a heat source. such as field work, outdoor travel adventure, Emergency Support Emergency Rescuemilitary garrison drills,s and other occasions. The utility model can be used for heating and heating of mobile and temporary facilities such as automobiles, ships, camping tents, and other temporary buildings.
Precautions for use:
(a) Make sure the battery has enough power to ensure the heater starts properly before use. When not in use for a long time, take out the battery and charge it regularly.
(b) Check the fuel tank to make sure the heater is running continuously. This product only uses diesel oil and should ensure the quality of diesel oil.
(c) Before starting the heater, the air valve on the fuel tank lid must be opened to prevent thefuel tank from being vacuumed.
| Model | NFGMH-04D | |
| Heating medium | Air | |
| Heat Level | 1-9 | |
| Heat rating | 1KW-4KW | |
| Fuel consumption | 0.1L/H - 0.48L/H | |
| Rated power consumption | <40W | |
| Rated voltage:(Max) | 16.8V | |
| Noise | 30 to 70dB | |
|
Ambient temperature
Heater
Fuel pump
|
Working | No working |
| -40° to +40°C | -40° to +85°C | |
| -40° to +50°C | -40° to +125°C | |
| Air inlet temperature | Max +28° | |
| Fuel | Diesel | |
| Internal fuel tank capacity | 3.7L(1.2Gallon) | |
| Host weight | 13kg | |
| The external dimension of the host | 410*265*280mm | |
This machine can generate electricity only after the machine is fired and runs stably, so it is necessary to install batteries when using the machine. After pressing the power button to switch on the power, observe whether the battery voltage is greater than 15.0v. if the voltage is lower than 15.0V, the battery can be charged to 15.0V-16.8V by inserting the charger into the charging port. if it is not convenient to use the charger to charge, you can use the cigarette lighter cable to plug into the DC input interface, and the cigarette lighter end can use the vehicle cigarette lighter or the outdoor power cigarette lighter port to power the machine before it can be turned on. After the machine is ignited and runs stably for at least 5 minutes, the cigarette lighter cable can be unplugged, and the machine can supply itself with electricity to achieve use without external power.
