High Quality EHPS Steering Pump For EV Truck
Hebei Nanfeng Group has a history of producing electric vehicle parts for over 30 years. Our company is the largest auto parts manufacturer in China. The steering motor is specially designed for electric vehicles and electric trucks and supports OEM customization.
Description
High-quality EHPS Steering Pump for EV truck
Products Description
Working principle of steering motor
A steering motor is a motor that works similarly to other motors. When current passes through the motor's coil, it rotates in a magnetic field. Permanent magnets generate the magnetic field in the steering motor on the stator and electromagnetic coils on the rotor. When current passes through the coil on the rotor, it generates a magnetic field and interacts with the permanent magnet on the stator,
The working principle of the steering motor can be explained in more detail as follows:
1. The power supply of the steering motor is turned on and current passes through the motor's coil.
2. Current passes through the coil on the rotor, generating a magnetic field.
3. The magnetic field of the rotor interacts with the magnetic field on the stator,
4. The rotational force of the rotor is transmitted to the output shaft to drive the vehicle forward or backward.
5. When the driver turns the steering wheel, the steering motor helps the vehicle steer.
|
Steering motor assembly performance parameters |
|||
|
Motor model |
EHPS-1018R3/19XB-010 |
||
|
Rated power (KW) |
3 |
Peak power (KW) |
7.5 |
|
Guangdong fixed voltage (VAC) |
237 |
Temperature control resistor type |
None |
|
Rated current (A.) |
12 |
Number of motor poles: |
8 poles (4 pairs of boards) |
|
Peak current (A) |
33 |
Stator wire resistance (0) |
0.8 (at 20℃) |
|
Rated frequency (HZ) |
66.67 |
Rated speed (r/min) |
1000 |
|
Peak torque (N.m) |
72 |
Rated torque (N.m) |
30 |
|
D-axis inductance|mH) |
6.88 |
Q-axis inductance|mH) |
10.87 |
|
Rated efficiency (%) |
≥92% |
Working day |
S2~3min |
|
Insulation level |
H level |
Cooling method: |
natural cooling |
|
Protection grade |
IP67 |
Working environment temperature: |
-40℃~+85℃ |
|
Motor type: |
SVC position sensorless permanent magnet synchronous motor |
||
Products Details
Products Application
The steering motor is one of the most important parts of a car. It is widely used in various types of cars such as cars, trucks, buses, etc. to help the vehicle turn and move forward or backward. Steering motors are also used in other types of vehicles such as boats and airplanes.
The steering motor is a very important automotive part that helps the vehicle turn and move forward or backward. The working principle and mechanism of the steering motor consist of multiple parts that work together to convert electrical energy into mechanical energy and help the vehicle turn. Understanding the working principle and mechanism of the steering motor is very important for maintaining and repairing cars.
