High Voltage Electric Vehicle PTC Heater



High Voltage Electric Vehicle PTC heater

1,Product Introduction



High voltage electric vehicle PTC heater is specially designed for electric vehicles. It can not only provide heat for the cockpit of new energy vehicles and meet the standard of safe defrosting and defogging, but also provide heat to other vehicle mechanisms (such as batteries) that require temperature regulation.



2,Product Parameter



Item	WPTC01-1	WPTC01-2
Heating output	6kw@10L/min,T_in 40℃
Rated voltage(VDC)	350V	600V
Working voltage(VDC)	250-450	450-750
Controller low voltage	9-16 or 18-32V
Control signal	CAN
Heater dimension	232.3 * 98.3 * 97mm
Installation dimension	144*128*119
Joint dimension	φ25, φ20mm
Heater weight	＜2.4kg
High voltage connector	PL082X-6.1-2.5, PL082X-6.1-4 (Amphenol): C10514N1-04-1-2 (JonHon)
Low voltage connectors	A02-ECC320Q60A1-LVC-4 (a)(Sumitomo adaptive drive module)



3,Product Feature

(1) Electricity is used to heat the antifreeze,and the heater is used to heat the interior of the car.

(2)Installed in the water cooling circulation system

(3)Warm air soft temperature controllable

(4)Adopt PWM to adjust and drive IGBT to adjust power

(5)With short-term heat storage function

(6)Vehicle cycle, support battery thermal management

(7)Environmental protection





4,Product Application



5,Product Detail



6,Product Qualifaction



7,FAQ



(1)Q:How can i get to your company?

    A:Our company is in Beijing, we can pick you up at the airport.

(2)Q:How can i trust your company?

    A:Our company has been producing heaters for more than 30 years, and has five factories, and is also the only designated supplier of Chinese military vehicles. You can completely trust us.

(3)Q:How you arrange shipment?

    A: By Sea/By Air/By Train/By Express.

(4)Q:What is your main market?

     A:In Asia, Europe, Americas, and etc.

(5)Can you give me a discount?

   A:Discount is available,but we have to see the real quantity,we have different price based on different quantity,how much discounts is determined by the quantity,moreover,our price is very competitive in the field.
