EV Car Cooling 3 Way Water Valve

Name: EV Car Cooling 3 Way Water Valve Suppliers and Manufacturers China - Factory Quotation - NANFENG
Brand: Nanfeng
SKU: 309230146

The three-way valve for air conditioning in new energy vehicles is a key component in the thermal management system, mainly used to precisely control the direction and flow rate of refrigerant in the air conditioning circuit.

Send Inquiry

Description

If you're looking for the ev car cooling 3 way water valve, welcome to wholesale the product from our factory. As one of the leading manufacturers and suppliers in China, we will offer you the best service and fast delivery. Now, check the quotation with our seller.

EV Car Cooling 3 Way Water Valve

EV Car Cooling 3 Way Water Valve

The electronic three-way valve, also known as the electronic three-way water valve, is the core electronic control actuator of the thermal management system of new energy vehicles. It replaces the mechanical thermostat of traditional fuel vehicles and uses electrical signals to precisely switch the coolant flow direction and distribute the water flow. It coordinates the hot and cold cycles of the battery, motor control, heat pump air conditioning, and defrosting system, and is a key component for realizing heat recovery and zoned temperature control of the whole vehicle.

3-way chilled coolant valves can be designed in diameters ranging from 16Øs to Ø25, requiring only changes to the pipe dimensions.

The Ø25 water valve allows for flow rate control from 5 L/MIN to 100 L/MIN.

The Problem vs. Solution

Conventional Valve Issues	Our Premium Solution
Inaccurate control causes temperature swings (±2°C)	Equal percentage flow characteristic delivers stable, precise output (±0.5°C)
Leakage at closed port wastes energy (bypass flow)	Bubble-tight shut-off (≤0.1% leakage) prevents energy loss
Short lifespan in chilled water applications (condensation, corrosion)	Stainless steel stem + brass/bronze body resists corrosion, 100,000+ cycles

Basic Structure

The whole machine consists of six parts: valve body flow channel, brushless drive motor, reduction gear set, rotary valve core, sealing assembly, and electrical control connector. It is equipped with three pipeline interfaces as standard, with the mainstream layout being one inlet and two outlets, which can realize three modes: water circuit diversion, loop switching, and proportional flow regulation.

Operating Principle

A 3-way chilled coolant valve regulates chilled water flow by redirecting rather than stopping flow, maintaining constant system pressure while modulating temperature.

product-871-562

Technical Specifications

No	Parameter name	Values
1	Water valve internal leakage	≤20mL/min (water test), 30kPa pressure difference
2	Water valve external leakage	≤5mL/min (gas test), 340kPa (gauge pressure)
3	Mode switching response time	<10s
4	Control method	LIN
5	Standard operating voltage	24V
6	Operating voltage range	20V~30V
7	Lifespan	300,000 switch cycles

Flow chart

3-way chilled coolant valve showcase

The installation location diagram is shown below (permissible installation angles).

installation method

Connection requirements with the vehicle:

ev 3 way value

Core advantages

Precise control and rapid response

Switching time is less than 10 seconds, supports continuous proportional adjustment, has no lag compared to mechanical valves, has higher temperature control accuracy, supports vehicle CAN/LIN bus communication, and can be matched with vehicle OTA intelligent control strategies.
Integrated lightweight design, simplified piping

A single valve replaces two sets of two-way valves, significantly reducing the number of water pipes and connectors in the vehicle, lowering assembly costs, and increasing the utilization rate of chassis space.
