PTC Electric Heater For EV

If you're looking for the ptc electric heater for ev, welcome to wholesale the product from our factory. As one of the leading manufacturers and suppliers in China, we will offer you the best service and fast delivery. Now, check the quotation with our seller.



PTC Electric Heater For EV





The 3kW PTC coolant heater is a core component of thermal management systems for new energy commercial vehicles and RVs; it utilizes PTC ceramic semiconductor technology to heat coolant circulating within the vehicle's fluid loop, rather than heating the air directly.





Power (KW)	3KW
Rated voltage(V)	350V
Supply voltage (V)	260-420V
Flow rate (L/h)	12 (±1)L/min
Baud rate	250K
Working temperature	-40℃~85℃
Storage temperature	-40℃~85℃
Control	CAN



Core Structure:

  PTC ceramic heating element (core heating component)

  Aluminum alloy water-cooled heat exchange chamber (coolant flow channels)

  High-voltage drive control board (MCU + IGBT power components)

  High-voltage connector, low-voltage control connector, and inlet/outlet ports

  Multiple temperature, current, and pressure sensors





-- Safe and reliable with self-limiting temperature and dry-burn protection: The PTC ceramic element does not glow red; power output automatically drops during water shortage or insufficient flow, complemented by software-based multi-level protections against over-temperature, over-current, over-voltage, under-voltage, and short circuits; features water-electricity isolation and high insulation standards.

-- High thermal efficiency: Thermal efficiency ≥95%; rapid heating upon activation with no high inrush current.

-- Controllable power: Supports stepless adjustment via vehicle CAN signals, delivering heat on demand to reduce battery energy consumption and extend driving range.

-- Vibration-resistant and durable: Eliminates issues with oxidation or burnout of resistance wires; suitable for the rugged operating conditions of commercial vehicles, with minimal power degradation.

-- Integrated design: Heating and drive control units are housed in a single casing for easy installation; connects directly in series with the cooling circuit.







PTC electric heaters can be used in vehicles such as new energy trucks, light-duty trucks, buses, RVs, and construction machinery to provide cabin heating and windshield defrosting and defogging functions.





The PTC electric heaters have obtained professional CE certification; the CE certificate is shown in the image below. Certain models have undergone professional EMC testing, and test reports are available upon request.









If you are interested in PTC coolant heaters or would like more information, please do not hesitate to contact us immediately; our professional sales team is ready to assist you.
