New Energy Vehicles Electric Air Conditioning Compressor
As the core power unit of modern air conditioning systems, electric air conditioning compressors are a revolutionary upgrade of traditional mechanically driven compressors and have become an indispensable key component in scenarios such as new energy vehicles and light electric equipment.
Description
If you're looking for the new energy vehicles electric air conditioning compressor, welcome to wholesale the product from our factory. As one of the leading manufacturers and suppliers in China, we will offer you the best service and fast delivery. Now, check the quotation with our seller.
Products Description
The working principle of an electric air conditioning compressor is based on efficient energy conversion and precise cycle control. It converts electrical energy into mechanical energy through a built-in high-performance electric motor, driving the internal scroll structure. The core scroll assembly consists of a fixed scroll plate and a moving scroll plate meshing with it at a 180° phase difference. As the moving scroll plate rotates eccentrically around the fixed scroll plate, it continuously draws low-temperature, low-pressure refrigerant into the crescent-shaped cavity, gradually compressing it into high-temperature, high-pressure gas before discharging it into the air conditioning system, completing the refrigeration cycle. The equipment is equipped with an intelligent electronic control unit (ECU), which automatically adjusts the motor speed according to actual temperature requirements, achieving precise temperature control and energy-saving operation.
Products parameter
| Model | NFEZC45 |
| Type | Electric scroll |
| Refrigerant | R290 |
| Work temperature | -20℃~110℃ |
| Storage temperature | -40℃~110℃ |
| Voltage resistance | leakage current<10mA@2000V(AC)/50HZ |
| Electrical isolation | ≥20MQ@1000V(DC) |
| Displacement | 45CC/r |
| Speed range | 800-8500rpm(Customizable) |
| Cooling method | sucion gas cooling |
| Refrigerant leakage rate | ≤5g/year |
| Lubricating oil | PVE |
| Shell | Cast Aluminum Alloy Shot Peening |
| Total weight (including oil) | ≤7.7kg(including oil) |
| Install position | near motor or gear case |
| Suction inner size | Φ28.4mm(Customizable) |
| Discharge inner size | Φ15.35mm(Customizable) |
Products details
Application Fields and Uses
Electric air conditioning compressors are increasingly widely used, covering multiple electrified drive fields. In the automotive field, they are widely used in pure electric vehicles, hybrid electric vehicles, fuel vehicles with frequent start-stop, as well as electric trucks, electric logistics tractors, and micro electric delivery vehicles. According to different voltage requirements, they can be divided into high-voltage and low-voltage models, which can be adapted to various vehicles and equipment.
Key Features
- First, outstanding energy efficiency: Driven independently by electricity, it does not rely on engine power, effectively reducing the load on the main power system and saving energy. Furthermore, intelligent start-stop and speed regulation functions significantly improve the driving range of new energy vehicles
- Second, smooth and quiet operation: The scroll structure and high-precision motor design minimize vibration and noise, creating a more comfortable operating environment, especially suitable for high-end models and equipment with stringent noise requirements.
- Third, flexible installation and compact structure: Not limited by engine layout, it can be flexibly installed in suitable locations. The integrated design of the motor, compressor, and controller makes the overall size smaller, saving installation space. In addition, the equipment is equipped with multiple protection functions such as undervoltage, overvoltage, overcurrent, and overheat protection. Its fully sealed structure ensures extremely high reliability and stable operation even in harsh working environments
