EV Car Cooling 3 Way Heater Water Valve
The three-way valve for air conditioning in new energy vehicles is a key component in the thermal management system, mainly used to precisely control the direction and flow rate of refrigerant in the air conditioning circuit.
Description
If you're looking for the ev car cooling 3 way heater water valve, welcome to wholesale the product from our factory. As one of the leading manufacturers and suppliers in China, we will offer you the best service and fast delivery. Now, check the quotation with our seller.
EV Car Cooling 3 Way Heater Water Valve
Products Description
The three-way valve for air conditioning in new energy vehicles is a key component in the thermal management system, mainly used to precisely control the direction and flow rate of refrigerant in the air conditioning circuit.
Electronic water valves use a DC motor and gearbox to control valve rotation, achieving reversing or flow regulation functions.
The valve position is controlled by the DC motor, gearbox, and position sensor. The position sensor outputs a corresponding voltage based on the valve angle.
Electronic water valves can be designed with diameters ranging from 16∅s to ∅25, requiring only changes to the pipe dimensions. The ∅25 valve allows for flow rate control from 5L/MIN to 100L/MIN.
Products Parameter
| No | Parameter name | Values |
| 1 | Water valve internal leakage | ≤20mL/min (water test), 30kPa pressure difference |
| 2 | Water valve external leakage | ≤5mL/min (gas test), 340kPa (gauge pressure) |
| 3 | Mode switching response time | <10s |
| 4 | Control method | LIN |
| 5 | Standard operating voltage | 24V |
| 6 | Operating voltage range | 20V~30V |
| 7 | Lifespan | 300,000 switch cycles |
Installation and Usage Guidelines
The installation location diagram is shown below (allowed installation angles):
Connection requirements with the vehicle:
★It is recommended to install rubber shock-absorbing pads at the bottom of the two M6 connection mounting holes, with a hardness of HA70~80.
Flow resistance curve
| Medium | 50% ethylene glycol |
| Temperature | 25℃ |
| Outer diameter of the pipe | Φ25 |
| Flow | 5-50L/min |
Products Details
Quality control
Outsource
Collaborate with suppliers to control component quality
Process
Strict process control and 6S management
Sales
Quality risk evaluation before/after sales
Delivery
No quality loss in delivery
Our Company
Our Exhibition
Products Application
FAQ
1. Q: Are you a manufacturer, trading company, or a third party?
A: We are a manufacturer, and our company has been established for over 30 years.
2. Q: Where is your factory located?
A: It lies in the industrial area of Wumaying of Nanpi county ofthe province of Hebei, covering an area of 80,000㎡.
3. Q: How can I get to your company?
A: Our company is in Beijing, and we can pick you up at the airport.
4. Q: If i will need to stay in your place for a few days, is it possible to book the hotel for me?
A: It's always my pleasure. Hotel booking service is available.
5. Q: What is your minimum order quantity? Can you send me samples?
A: Our MOQ is one set; samples are available.
6. Q: At what level of quality are your products?
A: We have got CE and ISO certificates so far.
7. Q: What is the delivery time of your product?
A: Generally, the product delivery time is within 30 days after payment, but special circumstances are not excluded.
8. Q: May I know which payment will be accepted by your company?
A:100% T/T in advance is available.
9. Q: About the after-sales service, how can you solve the problems occurred of your overseas customers in time?
A: Our warranty period is one year, and our service staff will do their best to solve any problems you have.
10. Q: How can I trust your company?
A: Our company has been producing heaters for more than 30 years, has five factories, and is also the only designated supplier of Chinese military vehicles. You can completely trust us.
